SPECIFICATIONS
Size
Metric
British
Max. Working Height
A
12.00m
39ft 4in
Max. Platform Height
B
10.00m
32ft 10in
Overall Length
C
2.48m
8ft 2in
Overall Width
D
1.15m
3ft 9in
Overall Height(Rails Up)
E
2.49m
8ft 2in
Overall Height(Rails Down)
F
1.96m
6ft 5in
Platform Size(Length×Width)
2.27m×1.12m
7ft 5in×3ft 8in
Platform Extension Size
G
0.90m
2ft 11in
Ground Clearance(Stowed/Raised)
0.10m/0.019m
4in/1in
Wheelbase
H
1.87m
6ft 2in
Turning Radius(Inside/Outside)
0m/2.20m
0in/7ft 3in
Tyres
φ381×127mm
φ381×127mm
